EP Series Replacement Pneumatic Motor

SKU: N/A

EP Series Air Motors produce maximum horsepower in a given space. The simplicity of their design has earned them a reputation of reliability. The high-torque developed by EP Series Air Motors is the result of a unique design that uses six light-blade rotors and a double-chambered power seal cylinder.

Reviews (0)

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Nominal Tube ID		Selection Chart		Series “EP” Specifications
Inches	(mm)	Motor Model	Motor Assy.	Motor Body Diam.	Rotor Thread	Hose and Coupling	CFM at 90 psi	Weight
Inches	(mm)	Motor Model	Motor Assy.	Motor Body Diam.	Rotor Thread	Hose and Coupling	CFM at 90 psi	lbs.	(Kg)
1 3/8	(34.9)	EP-137	4622- 0131	1 5/16	7/16 x 14	3/8	32	1 1/4	(.6)
1 1/2	(38.1)	EP-150	3942- 0143	1 7/16	7/16 x 14	1/2	45	1 13/16	(.8)
1 3/4	(44.5)	EP-175	2000- 0156	1 9/16	9/16 x 12	1/2	47	2 1/2	(1.1)
2	(50.8)	EP-200	2012- 0181	1 13/16	5/8 x 11	3/4	70	3 1/4	(1.5)
2 1/4	(57.2)	EP-225	7968- 0212	2 1/8	3/4 x 10		73	5	(2.3)
2 1/2	(63.5)	EP-250	2044- 0231	2 5/16	3/4 x 10		100	6 3/4	(2.8)
2 3/4	(69.9)	EP-275	2058- 0262	2 5/8	7/8 x 9	1	108	9 1/2	(4.3)
3	(76.2)	EP-300	2072- 0281	2 13/16	1 x 14	1	152	12 1/8	(5.5)
3 1/4	(82.6)	EP-325	2072- 0306	3 1/16	1 x 14	1	152	14 1/4	(6.5)
3 1/2	(88.9)	EP-350	2091- 0325	3 1/4	1 1/8 x 12	1	164	16	(7.3)
3 3/4	(95.3)	EP-375	2091- 0350	3 1/2			164	18 1/2	(8.4)
4	(101.6)	EP-400	2109- 0375	3 3/4			175	23	(10.4)
4 1/4	(108.0)	EP-425	2109- 0400	4				23 1/2	(10.7)
4 1/2	(114.3)	EP-450	2109- 0425	4 1/4				24	(10.9)
4 3/4	(120.1)	EP-475	2109- 0450	4 1/2				25 1/8	(11.6)
5	(127.0)	EP-500	2109- 0475	4 3/4				27 3/4	(12.6)
5 1/4	(133.4)	EP-525	3142- 0500	5	1 3/8 x 12	1	225	44 3/16	(20.0)
5 1/2	(139.7)	EP-550	3142- 0525	5 1/4				44 5/16	(20.1)
5 3/4	(146.1)	EP-575	3142- 0550	5 1/2				44 7/16	(20.2)
6	(152.4)	EP-600	3142- 0575	5 3/4				45 9/16	(20.7)
6 1/4	(158.8)	EP-625	3142-0600	6
6 1/2	(165.1)	EP-650	3142- 0625	6 1/4
6 3/4	(171.5)	EP-675	3142-0650	6 1/2
7	(177.8)	EP-700	3142-0675	6 3/4
7 3/8	(187.3)	EP-737	7258- 0712	7 1/8
7 3/4	(196.9)	EP-775	7258- 0737	7 3/8
8 1/2	(215.9)	EP-850	7258-0800	8
9	(228.6)	EP-900	7258-0850	8 1/2
9 3/4	(247.7)	EP-975	7260- 0925	9 1/4
10	(254.0)	EP-1000	7260-0950	9 1/2
10 1/4	(260.4)	EP-1025	7260-0975	9 3/4
11 1/2	(292.1)	EP-1150	7260-1100	11
11 3/4	(298.5)	EP-1175	7260- 1125	11 1/4
12	(304.8)	EP-1200	7262-1150	11 1/2
13 1/2	(342.9)	EP-1350	7262-1300	13
